Technical Details

• Power (Watts) 865W
• Features Adjustable Output, PMBus™, Remote Sense, Standby Output, Universal Input
• Size / Dimension 10.22" L x 6.46" W x 1.60" H (259.5mm x 164.0mm x 40.6mm)
• Mounting Type Chassis Mount
• Voltage - Input 85 ~ 264 VAC
• Type Enclosed
• Operating Temperature -40°C ~ 85°C
• Applications ITE (Commercial), Medical
• Approval Agency CSA, EN, IEC, UL
• Efficiency 93%
• Voltage - Output 1 5V
• Voltage - Output 2 24V
• Voltage - Output 3 5V
• Voltage - Output 4 24V
• Number of Outputs 8
• Voltage - Isolation 4 kV
• Voltage - Output 5 12V
• Voltage - Output 6 5V
• Standard Number 60601-1; 60950-1; 62368-1
• Current - Output 1 21 A
• Current - Output 2 8.3 A
• Current - Output 3 6 A
• Current - Output 4 3 A
• Current - Output 5 15 A
• Current - Output 6 6 A
