Technical Details

• Power (Watts) 120W
• Features Adjustable Output, DC Input Capable, PFC, Universal Input
• Size / Dimension 3.15" L x 2.44" W x 1.57" H (80.0mm x 62.0mm x 40.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 85 ~ 264 VAC, 127 ~ 370 VDC
• Type Enclosed, Conformal Coated
• Operating Temperature -40°C ~ 85°C (With Derating)
• Applications Household Appliances, ITE (Commercial), Medical
• Approval Agency CB, CE, cURus, EN, UKCA
• Efficiency 94%
• Voltage - Output 1 54V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 60601-1; 62368-1
• Current - Output 1 2.22 A
