Technical Details

• Power (Watts) 500W
• Features Adjustable Output, DC Input Capable, PFC, Remote Sense, Universal Input
• Size / Dimension 6.30" L x 3.39" W x 1.69" H (160.0mm x 86.0mm x 43.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 90 ~ 264 VAC, 127 ~ 370 VDC
• Type Enclosed, Conformal Coated
• Operating Temperature -40°C ~ 70°C (With Derating)
• Applications Household Appliances, ITE (Commercial), Medical
• Approval Agency CB, CE, cURus, EN, IEC, UKCA, UL
• Efficiency 92%
• Voltage - Output 1 15V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 60601-1; 62368-1
• Current - Output 1 33.3 A
