Technical Details

• Power (Watts) 252W (450W Forced Air)
• Features Adjustable Output, DC Input Capable, PFC, Remote Sense, Standby Output, Universal Input
• Size / Dimension 5.12" L x 3.39" W x 1.69" H (130.0mm x 86.0mm x 43.0mm)
• Mounting Type Chassis Mount
• Voltage - Input 90 ~ 264 VAC, 127 ~ 370 VDC
• Type Enclosed, Conformal Coated
• Operating Temperature -40°C ~ 70°C (With Derating)
• Applications Household Appliances, ITE (Commercial), Medical
• Approval Agency CB, CE, cURus, EN, IEC, UKCA, UL
• Efficiency 93%
• Voltage - Output 1 24V
• Minimum Load Required No
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 60601-1; 62368-1
• Current - Output 1 18.75 A
