Technical Details

• Power (Watts) 90W
• Features Baseplate, DC Input Capable, PFC, Universal Input
• Size / Dimension 4.66" L x 2.47" W x 1.52" H (118.3mm x 62.7mm x 38.7mm)
• Mounting Type Chassis Mount
• Voltage - Input 85 ~ 264 VAC, 120 ~ 370 VDC
• Type Enclosed
• Operating Temperature -40°C ~ 90°C (With Derating)
• Applications Household Appliances, ITE (Commercial), Medical
• Approval Agency CE, cURus, EAC, UKCA
• Efficiency 90%
• Voltage - Output 1 48V
• Number of Outputs 1
• Voltage - Isolation 4 kV
• Standard Number 60335-1; 60601-1; 62368-1
• Current - Output 1 1.87 A
